Commercial display with large screen DIPANEL-7000-BLK and a built-in digital signage media player for large shopping malls, railway stations, metro stations and subways. Has a large LED screen with vandal-proof protection from bumps and scratches, built-in standalone media player or management system via the Internet. It turns on and off automatically on a schedule. Can be equipped with a computer based on Windows, Linux, or Android. It is also possible to install a touch-screen film, which will upgrade digital signage monitor into internet kiosk or interactive display. This screen can be used in both landscape and portrait orientation. In the case of vertical advertising display, model DIPANEL-7000-BLK will look as vandal-proof version of digital advertising display DILUX series.
The information is delivered to the audience not only through images but also through sound. Thanks to built-in loudspeakers of this digital signage display. Two speakers, 6 watts each will complement the image that is displayed on DIPANEL-7000-BLK, and will have a much greater influence on the target audience than just a picture.
Digital Signage remote management function can be used to remotely download ad and info content to multiple displays simultaneously, and synchronize image on these displays.
DIPANEL-7000-BLK Advertising display can be equipped with a motion sensor with a high sensitivity level and 6 programmable touch keys to use it as an informational interactive display in museums, airports, malls, outlets and shopping centers.
We sell digital signage displays worldwide. We can produce screen sizes from 10 to 150 inches. Call or email us now to know the price and delivery time!


Basic functions of LCD ad player

Auto start of displaying video at power-up, no need to turn on manually. Automatic on and off on a schedule. Support Full HD video, image files, MP3, lossless audio. Automatic playlist repeat around the clock all year round. Automatic restart in case of power failure. Scroll text with the color setting and size of letters and the substrate, the Update of information on the SD flash card c USB flash, view Statistics of mediaflow, Optional remote control via WIFI, 3G, 4G Internet. You can update your playlist, media, schedule. Watch full list of this model functions...


Main features of DIPANEL Digital Signage Display

Rugged vandal-proof metal housing with simple design. Can be installed on the wall, the ceiling, on the Desk or on a shelf of a store. Can be used as a monitor for bus, taxi, metro cars, and train stations. Equipped with transparent screen protection made of tempered glass or plastic. Flash card, and USB flash is lockable to protect against theft. Multilingual settings menu. Built-in speakers 2x2W or 2x4W, see the full list of features...


Options of DIPANEL display series

  • Option: Remote display management via LAN/Internet remote updating of media files and playlists
  • Option: Built-in Android or Linux PC
  • Option: Built-in Windows PC
  • Option: Touch screen (touchscreen)
  • Option: Motion sensor
  • Option: Hot and cold conditions version
  • Option: Ultrabright screen for visibility in sunlight
  • Option: I/O Interface RS232
  • Option: Built-in memory
  • Option: Internet WiFi
  • Option: Internet – 3G / 4G
  • See the full list of options...



Interfaces:

  • SD flash card
  • CF flash card
  • USB flash
  • Option: AV input(CVBS)
  • Option: HDMI video + audio
  • Option: DisplayPort
  • Option: VGA / RGB video
  • Option: Audio input or output
  • Option: Antenna (coaxial cable)
  • Option: Internet – Wire RJ45
  • Option: Internet WiFi
  • Option: Internet – 3G / 4G
  • See the full list of interfaces...

Specification DIPANEL-7000-BLK

General
Application Bus display, Transport advertising screen, Indoor Advertising monitor, LCD advertising player, Digital signage, Standalone LCD ad player, Advertising display
Housing material Metal
Color Black, White (other by request)
Power input 9-30V for transport, 100-300V for indoor
Power consumption 120 W
Operating System AdPlayer / Windows / Linux / Android
OSD language English, Chinese, Japanese, Spanish, Deutsche, French, Portuguese, Italian, Russian ...
Speakers 2x16W
Internal memory No
Optional internal memory 2-32GB
Storage temperature -35...+45C (-15...113F)
Operation temperature -25...+45C (-13...113F)
Flash memory support SD, SDHC, MMC/MS, USB flash
Flash memory anti-theft Cardreader door with lock
Mount method Wall, Сeiling, Handrail, Stand, VESA75/100 Mounting
Accessories Mounting kit, Remote Control, Manual
May also need SD/SDHC/MMC/MS or USB flash
Screen
Screen size 70 inch
Aspect ratio 16:9
Available sizes 10, 12, 15, 17, 19, 22, 24, 32, 42, 55, 65 ,70 inch
Screen protection Tempered glass or Acrylic glass, 1-6 mm ( 3/64 - 1/4 inch)
Screen type LCD
Optional screen type LED, IPS
Resolution 1920x1080
View angle H/V 179/178
Brightness 300 cd/m2
Contrast ratio 1200:1
Supported colours 16.7 million
Response time 3 ms
Media support
Video files AVI, MPG, VOB, MPEG-1, MPEG-2, MPEG-4, H264, Matroska MKV (FullHD)
Picture files JPG, GIF, BMP, PNG
Audio files MP3, WMA, OGG, WAV, AAC, FLAC
Size and Weight
Product size (mm) by request
Product weight (kg) by request
Carton size (mm) by request
Carton G.W. (kg) by request
Packing details by request
