Advertising vandal-proof display DIPANEL-3200-BLK comes in a sturdy metal case with a glass or plastic screen protection. The monitor shows slides and photos in GIF/JPG/PNG images, videos AVI/MPG/MOV Full HD, as well as FLAC and MP3 audio. This became possible due to the internal Full HD media player. The advertising message on this “digital signage poster inch will be automatically displayed on a circle in the correct sequence. Built-in multimedia advertising player allows you to play photo with music and videos with a resolution up to 1080 p. Therefore, the owner of Advertising display for digital signage can start an advertising campaign both in video format and in static images.
Option of remote content management for electronic LCD display Digital Signage allows you to quickly and easily download any content using network RJ45 Ethernet or wi-fi, GSM 3G. With option of wireless networks 802.11 b/g/n and Ethernet network connection using RJ45 connector electronic poster DIPANEL-3200-BLK provides fast update of promotional video and slides from a laptop or personal computer.
Basic functions of LCD ad player
Auto start of displaying video at power-up, no need to turn on manually. Automatic on and off on a schedule. Support Full HD video, image files, MP3, lossless audio. Automatic playlist repeat around the clock all year round. Automatic restart in case of power failure. Scroll text with the color setting and size of letters and the substrate, the Update of information on the SD flash card c USB flash, view Statistics of mediaflow, Optional remote control via WIFI, 3G, 4G Internet. You can update your playlist, media, schedule. Watch full list of this model functions...
Main features of DIPANEL Digital Signage Display
Rugged vandal-proof metal housing with simple design. Can be installed on the wall, the ceiling, on the Desk or on a shelf of a store. Can be used as a monitor for bus, taxi, metro cars, and train stations. Equipped with transparent screen protection made of tempered glass or plastic. Flash card, and USB flash is lockable to protect against theft. Multilingual settings menu. Built-in speakers 2x2W or 2x4W, see the full list of features...
Options of DIPANEL display series
- Option: Remote display management via LAN/Internet remote updating of media files and playlists
- Option: Built-in Android or Linux PC
- Option: Built-in Windows PC
- Option: Touch screen (touchscreen)
- Option: Motion sensor
- Option: Hot and cold conditions version
- Option: Ultrabright screen for visibility in sunlight
- Option: I/O Interface RS232
- Option: Built-in memory
- Option: Internet WiFi
- Option: Internet – 3G / 4G
- See the full list of options...
Interfaces:
- SD flash card
- CF flash card
- USB flash
- Option: AV input(CVBS)
- Option: HDMI video + audio
- Option: DisplayPort
- Option: VGA / RGB video
- Option: Audio input or output
- Option: Antenna (coaxial cable)
- Option: Internet – Wire RJ45
- Option: Internet WiFi
- Option: Internet – 3G / 4G
- See the full list of interfaces...
Specification DIPANEL-3200-BLK
General | |
Application | Bus display, Transport advertising screen, Indoor Advertising monitor, LCD advertising player, Digital signage, Standalone LCD ad player, Advertising display |
---|---|
Housing material | Metal |
Color | Black, White (other by request) |
Power input | 9-30V for transport, 100-300V for indoor |
Power consumption | 35W |
Operating System | AdPlayer / Windows / Linux / Android |
OSD language | English, Chinese, Japanese, Spanish, Deutsche, French, Portuguese, Italian, Russian ... |
Speakers | 2x4W |
Internal memory | No |
Optional internal memory | 2-32GB |
Storage temperature | -35...+45C (-15...113F) |
Operation temperature | -25...+45C (-13...113F) |
Flash memory support | SD, SDHC, MMC/MS, USB flash |
Flash memory anti-theft | Cardreader door with lock |
Mount method | Wall, Сeiling, Handrail, Stand, VESA75/100 Mounting |
Accessories | Mounting kit, Remote Control, Manual |
May also need | SD/SDHC/MMC/MS or USB flash |
Screen | |
Screen size | 32 inch |
Aspect ratio | 16:9 |
Available sizes | 10, 12, 15, 17, 19, 22, 24, 32, 42, 55, 65 ,70 inch |
Screen protection | Tempered glass or Acrylic glass, 1-6 mm ( 3/64 - 1/4 inch) |
Screen type | LCD |
Optional screen type | LED, IPS |
Resolution | 1920x1080 |
View angle H/V | LCD:85/85/85/65 LED:88/88/88/88 |
Brightness | 300 cd/m2 |
Contrast ratio | 900:1 |
Supported colours | 16.7 million |
Response time | 3 ms |
Media support | |
Video files | AVI, MPG, VOB, MPEG-1, MPEG-2, MPEG-4, H264, Matroska MKV (FullHD) |
Picture files | JPG, GIF, BMP, PNG |
Audio files | MP3, WMA, OGG, WAV, AAC, FLAC |
Size and Weight | |
Product size (mm) | by request |
Product weight (kg) | by request |
Carton size (mm) | by request |
Carton G.W. (kg) | by request |
Packing details | by request |
