12 inch Digital Signage display DIPANEL-1200-BLK is great solution for advertising in retail stores, in shop windows, and at the reception. Bright advertising screen shows a custom banner ads and video files with high resolution. This vandal-proof advertising monitor has an aspect ratio of 4:3. There are all the necessary equipment for automatic operation integrated inside display – power supply, digital signage player, card reader for USB and SD flash.
This display is recommended for the following digital signage applications:
Digital signage advertising display on the shelf of the store or near the showcase
The display on the POS monitor or rack with the goods
Advertising screen for taxi. Can be placed between the front seats
Commercial display in the beauty shop on the shelf or on the mirror
Promotional display in the window of the pharmacy or cosmetics shop
Commercial display or information display near the Elevator
The pictures on the digital signage display perfectly highlighted with a LED backlight, emphasizing clarity, brightness, and high quality picture. DIPANEL-1200-BLK Advertising monitor is equipped with a standalone advertising player, or digital signage player with management over the Internet. Any of these players support popular formats of JPEG photos and slides, and AVI videos. Liquid crystal display capable of displaying digital image offline - without a computer or an external player. DIPANEL-1200-BLK commercial display with high resolution screen can read videos from a memory card and USB2.0 flash drives. Advertising screen for business use (commercial advertising display) can be set to show your favorite pictures and videos on a circle, without turning off and any service.
Basic functions of LCD ad player
Auto start of displaying video at power-up, no need to turn on manually. Automatic on and off on a schedule. Support Full HD video, image files, MP3, lossless audio. Automatic playlist repeat around the clock all year round. Automatic restart in case of power failure. Scroll text with the color setting and size of letters and the substrate, the Update of information on the SD flash card c USB flash, view Statistics of mediaflow, Optional remote control via WIFI, 3G, 4G Internet. You can update your playlist, media, schedule. Watch full list of this model functions...
Main features of DIPANEL Digital Signage Display
Rugged vandal-proof metal housing with simple design. Can be installed on the wall, the ceiling, on the Desk or on a shelf of a store. Can be used as a monitor for bus, taxi, metro cars, and train stations. Equipped with transparent screen protection made of tempered glass or plastic. Flash card, and USB flash is lockable to protect against theft. Multilingual settings menu. Built-in speakers 2x2W or 2x4W, see the full list of features...
Options of DIPANEL display series
- Option: Remote display management via LAN/Internet remote updating of media files and playlists
- Option: Built-in Android or Linux PC
- Option: Built-in Windows PC
- Option: Touch screen (touchscreen)
- Option: Motion sensor
- Option: Hot and cold conditions version
- Option: Ultrabright screen for visibility in sunlight
- Option: I/O Interface RS232
- Option: Built-in memory
- Option: Internet WiFi
- Option: Internet – 3G / 4G
- See the full list of options...
Interfaces:
- SD flash card
- CF flash card
- USB flash
- Option: AV input(CVBS)
- Option: HDMI video + audio
- Option: DisplayPort
- Option: VGA / RGB video
- Option: Audio input or output
- Option: Antenna (coaxial cable)
- Option: Internet – Wire RJ45
- Option: Internet WiFi
- Option: Internet – 3G / 4G
- See the full list of interfaces...
Specification DIPANEL-1200-BLK
General | |
Application | Indoor Advertising monitor, LCD advertising player, Digital signage, Standalone LCD ad player, Advertising display |
---|---|
Housing material | Metal |
Color | Black, White, Silver, Golden (other by request) |
Power input | 100-300V for indoor |
Power consumption | 13W |
Operating System | AdPlayer / Windows / Linux / Android |
OSD language | English, Chinese, Japanese, Spanish, Deutsche, French, Portuguese, Italian, Russian ... |
Speakers | 2x4W |
Internal memory | No |
Optional internal memory | 2-32GB |
Storage temperature | -35...+45C (-15...113F) |
Operation temperature | -25...+45C (-13...113F) |
Flash memory support | SD, SDHC, MMC/MS, USB flash |
Flash memory anti-theft | Cardreader door with lock |
Mount method | Wall, Сeiling, Handrail, Stand, VESA75/100 Mounting |
Accessories | Mounting kit, Remote Control, Manual |
May also need | SD/SDHC/MMC/MS or USB flash |
Screen | |
Screen size | 12 inch |
Aspect ratio | 4:3 |
Available sizes | 10, 12, 15, 17, 19, 22, 24, 32, 42, 55, 65 ,70 inch |
Screen protection | Tempered glass or Acrylic glass, 1-6 mm ( 3/64 - 1/4 inch) |
Screen type | LCD |
Optional screen type | LED, IPS |
Resolution | 1024x768 |
View angle H/V | LCD:85/85/85/65 LED:88/88/88/88 |
Brightness | 250 cd/m2 |
Contrast ratio | 900:1 |
Supported colours | 16.7 million |
Response time | 3 ms |
Media support | |
Video files | AVI, MPG, VOB, MPEG-1, MPEG-2, MPEG-4, H264, Matroska MKV (FullHD) |
Picture files | JPG, GIF, BMP, PNG |
Audio files | MP3, WMA, OGG, WAV, AAC, FLAC |
Size and Weight | |
Product size (mm) | by request |
Product weight (kg) | by request |
Carton size (mm) | by request |
Carton G.W. (kg) | by request |
Packing details | by request |
